• (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• (HD) 1920 x 1080i 50, 59.94
• (HD) 1280 x 720p 50, 59.94, 60
• (SD) 625i 50
• (SD) 525i 59.94

• 10-bit, 4:2:2, uncompressed

• NMOS
• Ember Plus (no discovery, control only)

• SMPTE ST 2110
  • 2x SFP+ Cages - SFPs not included
• Recommended 10 GigE SFP+ modules:
  • Arista Networks SFP-10G-SR Compatible 10GBASE-SR
  • Fiberstore SFP-10R-85 10G SFP+ 850nm
  • Finisar FTLX1471D3BCL (for single mode 1310nm)
  • Mellanox MFM1T02A-SR 850nm 10G

  Note: Maximum supported SFP+ power is 500 mWatts per SFP+ cage

• Single channel input
• Dual channel input for hitless switching (based on SMPTE ST 2022-7)

• 4:2:2 10-bits/pixel (embedded audio)

• Up to 8-Channel, SDI embedded audio, 24-bit per channel, 48 kHz synchronous

• Levels at -10 dBu (nominal)

• Analog Color Black or HD tri-level sync
• Refereninput is terminated into 75 ohms

• 1x RJ-45 for 10/100/1000 Base-T Ethernet
  • Web and REST clients supported
• 1x USB 2.0 Mini-B connector
  • AJA eMini-Setup of network parameters via local desktop computer

• 5.07" x 0.94" x 5.06" (128.78 x 23.88 x 128.52 mm)

• 0.6 lb (0.3 kg)

• 5-20VDC Regulated, 13 Watts, Power supply required (DWP-U-R1 included withaus Kunststoffrchase)

• Safe Operating Temperature: 0 to 40 C (32 to 104 F)
• Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
